Description
| Cellular Parameters | ||||
| Frequency Band | Standard version:
5G: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78 4G: B1/B3/B5/B7/B8/B20/B28/B38/B40/B41/B42*/B43* 3G: B1/B2/B5/B8 Remarks:Â [*]Â It can be supported, but it needs extra debugging or affects other frequency bands. |
Optional version:
5G NR:n2/n5/n12/n25/n66/n41/n48*/n71*/n77/n78 4G:B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B41/B42*/B43*/B48*/B66/B71* 3G：B2/B4/B5 Remarks: [*] It can be supported, but it needs extra debugging or affects other frequency bands. |
||
| Protocol | 3GPP Rel.15，5G NR，SA/NSA，Sub 6G/LTE Category 18 | |||
| Theoretical Bandwidth | NR: Downlink/Uplink up to 2.77Gbps/1.25Gbps
LTE: Downlink/Uplink up to 1.2Gbps/150Mbps WCDMA: Downlink/Uplink up to 42.2Mbps/11.5Mbps |
|||
| WIFI Parameters | ||||
| WIFI Protocol | IEEE802.11 a/b/g/n/ac/ax | |||
| WIFI Frequency Band | 2.4GHz+5GHz | |||
| Channel Bandwidth | 802.11a：Up to 54Mbps
802.11b：Up to 11Mbps 802.11g：Up to 54Mbps 802.11n：Up to 300Mbps 802.11ac:Up to 866Mbps 802.11ax:Up to 1201Mbps |
|||
| Users | 16 users | |||
| Hardware | ||||
| Chipset | MT6877(MediaTek Dimensity 900),6nm | |||
| WIFI:Â MT6635 | ||||
| Memory | LPDDR4X 2GB RAM+EMMC 16GB ROM | |||
| Antenna | Cellular:Â 4*4 MIMO
WIFI: 2*2Â MIMO |
|||
| LCD | 2.4‘‘TFT MIPI(LCD or LED) | |||
| Power Supply | ||||
| Charge | 5V/2A(Type C) | |||
| Battery | 4400mAh Polymer battery(could be customized) | |||
| Interfaces | ||||
| SIM Card | Nano SIM(4FF)
ESIM optional |
|||
| USB Port | Type C | |||
| Button | POWER On/Off, RESET,WPS | |||
| Physical Characteristics | ||||
| Dimension | 125x70x17 mm | |||
| Operating Temperature | 0~+55ºC | |||
| Storage Temperature | -20~+70ºC | |||
| Humidity | 95% (No-condensing) | |||
